Hydraulic Clamping And Lamination Hot Press

Hydraulic Clamping And Lamination Hot Press

P021

Product Description

  • Automatic feeding & gluing
  • Automatic board arrangement
  •  Automatic in-feeding and clamping
  • Electrical heating function
  • There is install the stainless steel on the surface of platens
  • PLC Control
  • With two function,clamping and lamination

Hydraulic Clamping And Lamination Hot Press   Hydraulic Clamping And Lamination Hot Press   Hydraulic Clamping And Lamination Hot Press
PLC Control   High temperature-resistant feeding structure   Toshiba high temperature pump heating system

Max Clamping Dimension 2900mm × 1220 mm
Max Clamping Thickness 50mm
Max Clamping Pressure (transverse) 30T (2.5kg/cm²)
Clamping Cylinder Q.ty 10 pcs
Max Lamination Area 2900 × 1220mm
Opening Betweeen Platens 100T (2.6kg/cm²)
Feeding Speed 250mm
Feeding Power 30m/min
Heating Power 36kW
Max.Temperature 120℃
Installed Power 12kW
Overall Dimension 6500 × 4300 × 1900mm
